Sensor Signal Conditioning MCU

11/11/2022

The BH66F535 is able to condition sensor signals and then transmit out on its analog or digital interfaces after conditioning.

With its internal 24-bit A/D converter, the BH66F5350 provides a high accuracy measurement conversion function for various sensors and its low temperature drift characteristic makes it suitable for use in industrial applications. The device also supports a variety of analog and digital output interfaces. Its fully integrated 12-bit D/A converter supports absolute output voltage as well as supporting interfaces with an output current range of 4mA to 20mA. The digital output interfaces include a PWM output as well as I²C, SPI and UART interface types.

Main Features

CPU Features:

  • Operating voltage:
    - fSYS=4MHz: 2.2V~5.5V
    - fSYS=8MHz: 2.2V~5.5V
    - fSYS=12MHz: 2.7V~5.5V
  • Up to 0.33μs instruction cycle with 12MHz system clock at VDD=5V
  • Power down and wake-up functions to reduce power consumption
  • Oscillator type
    - Internal High Speed 4/8/12MHz RC – HIRC
    - Internal Low Speed 32kHz RC – LIRC

Peripheral Features:

  • Flash Program Memory: 8K×16
  • Data Memory: 512×8
  • True EEPROM Memory: 128×8
  • Watchdog Timer function
  • In Application Programming function – IAP
Documents Tech question
Holtek BH66 F5350

Sensor Signal Conditioning MCU

  • Applications
  • Technologies
  • Manufacturer
  • Documents

Applications & Markets

  • 7 Io T Industry 4 0

    IIoT & Industry 4.0

  • 5 Industrial Automation

    Factory & Industrial Automation, Robotics

Technologies

  • Shutterstock 1632356350

    Microcontroller, microprocessors & memory ICs

Holtek

Holtek Semiconductor is a leading professional IC design house in Taiwan having its major business activities focused in the area of microcontroller and peripheral component design.

Read more
Holtek semiconductor logo web

Documents

  • Holtek BH66 F5350v100 Datasheet
