Product news

Pulse is excited to announce the launch of an automotive grade IATF certified version of our popular PH9505 series of high isolation current sense transformer, which remains same platform and footprint size with PH9505

Elegant and reliable solutions for touchscreens

Our surface-mounted power inductors are designed for applications ranging from power supply to power converters.

Pulse Electronics’ newest BMS transformers, at 3.45mm high, are the markets lowest profile packages and complement the current BMS range of products.

Market leading PulsejackTM, integrated connector modules (ICMs) for high speed 10GBase-T over copper are now expanded with the introduction of the JXT4- family.

Pulse Electronics' modules with 40 W and 70 W PoE are designed for outdoor and industrial environments

Electric Vehicles (EVs), generally refer to cars with electric motor powered by battery rather than internal combustion engine powered by gasoline.

Eaton’s broad selection of high Q chip inductors provides design flexibility in many RF wireless applications in multilayer and wire-wound configurations, with industry sizes 0603 to 1206 (MCQ family), 0402 to 0805 (MCL family), and 1008 and 1210 (WCL family).

The Watts range for the standard core type EP is 3W-70W. For the low-profile core shape EFD this Is 8W-90W. The wattage from 3W to 90W.

A new PAS6322 series of low-profile current sense transformers become part of the company’s diverse line of current sense transformers depicted above (PAS6322 not shown).

iNRCORE offers current sense transformers with additional clips for secure core halves bonding.

The HDRC2012 series Common Mode Choke Coil package size is 2.0x1.2x1.2mm, and the common mode impedance is 30-1000Ω.

Power over Ethernet , or PoE , describes the technology that pass electric power along with data on twisted pair Ethernet cabling.

Pulsejack^TM, integrated connector modules (ICMs) are ideal for use in the latest LTE and 5G Mobile Wireless Access Points (WAPs) and other Industrial and outdoor uses.

The PulseChip^TM 1Gigabit, 2.5Gigabit, 5Gigabit, and 10Gigabit single transformers to support standard and Power over Ethernet (PoE) applications for the commercial and industrial temperature rated environments.

The new EP13R uses the industry standard EP13 footprint but with an increased bobbin flange to enable reinforced safety insulation, 8.0mm of creepage distance and 3000Vrms isolation.

Power Inductors / Power Transformers / Current Sense Magnetics / Common Mode Chokes / Isolation Transformers

Eaton’s EXL is a family of next-generation pressed powder high-current inductors.
