The A750Pi and A650Si/Sc Series embedded SSDs are built on 3D triple level cell (TLC) NAND flash. Manufactured using a new die package, the Serial ATA solid state drives (SATA SSDs) deliver 66% higher endurance in native TLC mode and 50% higher in pseudo single level cell (pSLC) mode, making them on par with drives built on multi-level cell (MLC) and SLC flash, respectively.
The new SSDs come in M.2 2280 and 2242 as well as 2.5” and mSATA form factors. A750Pi/A650Si SSDs support industrial temperature (I-Temp) ranges from -40°C to 85°C to perform reliably even when operating under extreme and harsh conditions. A650Sc SSDs can support commercial operating temperatures (C-Temp) from 0°C to 70°C.
A650Si/Sc with native TLC NAND flash have capacities from 120 to 1920 GB, while A750Pi drives configured in pSLC offer 80 to 640 GB. Depending on project and specific part number request, ATP’s new SATA embedded SSDs are also available as self-encrypting drives (SEDs) featuring AES-256 encryption and Opal TCG 2.0-compliant security.
ATP’s advanced pSLC technology extends the general endurance to more than 10 times that of TLC-based products. It also improves the sustained write performance and reliability of the drive, making the drives suitable for write-intensive applications
ATP Electronics is the leading provider of “Industrial Only" high-performance, high-quality and high-endurance NAND flash products and DRAM modules.
