New 22nm High-Performance FPGA family - Arora V

30/09/2022

New generation Arora V high performance FPGA family utilizing advanced 22nm SRAM technology and integrating 270Mbps-12.5Gbps high speed SerDes interfaces, PCIe 2.1 hard core with support for PCIe x1, x2, x8 modes, along with MIPI hard core single lane module at up to 2.5Gbps, and DDR3 interfacing at speeds up to 1333 Mbps. The first family device, GW5AT-138FC676, features 138K LUT logic resources, 6.4MB block RAM, 1.1MB distributed SRAM, along with advanced DSP blocks, and integrated ADC. Future family devices include 25K (non-Serdes) and 60K LUT devices

Main Features

FPGA Fabric Architecture

  • Up to 138K LUTs(GW5A(T)-138)
  • Up to 23K LUTs(GW5A-25)
  • Block SRAM with multiple modes
  • Single Port, Semi-Dual Port, True Dual Port, and Semi Dual Port with ECC function
  • Byte write enable
  • ECC error detection and correction

Flexible GPIO

  • Adjustable drive strength
  • 4mA, 8mA, 12mA, 16mA, 24mA drive
  • Bus keeper, pull up/down and open drain
  • Hot Socket and input hysteresis

ADC

  • 60dB SNR and 1kHz Signal Bandwidth
  • Flexible X-channel oversampling ADC
  • No external voltage source required

Configuration & Programming

  • JTAG, SSPI, MSPI, CPU, and SERIAL
  • Background programming
  • SPI Flash Programming and Boot
  • Multi-boot

High Speed Interfaces

  • SERDES(GW5AT-138)
  • 270Mbps-12.5Gbps operation
  • CDR (Clock Data Recovery)
  • Dedicated RX and TX Channels
