High performance & energy-efficient 10″-21.5″ multi-touch computer

27/11/2020

MTC-7000 Series is powered by 8th generation Intel® Core™ i7/i5/i3 processor (Whiskey Lake) and features leading performance and innovative power management functions. It supports projected capacitive multi-touch screen, fanless design, -5°C to 55°C operating temperature, IP65 certified panel protection, 9V to 48V wide range DC-in power input. MTC-7000 Series is outfitted with 2 GigE LAN, 4 10G USB, 2 COM for flexible connectivity

MTC-8000 Series is powered by Intel Atom® x7-E3950 Processor and features outstanding performance and innovative power management functions. It supports projected capacitive multi-touch screen, fanless design, -10°C to 60°C operating temperature, IP65 certified panel protection, 9V to 36V wide range DC-in power input. Vecow MTC-8000 Series is outfitted with 2 GigE LAN, 4 USB, 2 COM for flexible connectivity and is ideal for AOI, HMI, Retail, AGV Truck, Security and any AIoT/Industry 4.0 applications.

Documents Tech question
6404 1

High performance & energy-efficient 10″-21.5″ multi-touch computer

  • Features
  • Applications
  • Technologies
  • Manufacturer
  • Documents

MTC-7021W

  • 21.5″ 1920 x 1080 (16:9) Full HD TFT LED LCD
  • 10-point Projected Capacitive Multi-touch Screen
  • 8th Generation Intel® Core™ i7/i5/i3 U-series Processor (Whiskey Lake)
  • Fanless design supports -5°C to 55°C operating temperature
  • 4-port 10G USB 3.1 Gen 2
  • Easy-access external SSD/HDD kit
  • DC 9V to 48V wide range power input
  • Supports Panel Mount and VESA Mount (75 x 75, 100 x 100)
  • IP65 Front Panel Protection
  • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS

MTC-7015W

  • 15.6″ 1366 x 768 (16:9) WXGA TFT LED LCD
  • 10-point Projected Capacitive Multi-touch Screen
  • 8th Generation Intel® Core™ i7/i5/i3 U-series Processor (Whiskey Lake)
  • Fanless design supports -5°C to 55°C operating temperature
  • 4-port 10G USB 3.1 Gen 2
  • Easy-access external SSD/HDD kit
  • DC 9V to 48V wide range power input
  • Supports Panel Mount and VESA Mount (75 x 75, 100 x 100)
  • IP65 Front Panel Protection
  • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS

MTC-7015

  • 15″ 1024 x 768 (4:3) XGA TFT LED LCD
  • 10-point Projected Capacitive Multi-touch Screen
  • 8th Generation Intel® Core™ i7/i5/i3 U-series Processor (Whiskey Lake)
  • Fanless design supports -5°C to 55°C operating temperature
  • 4-port 10G USB 3.1 Gen 2
  • Easy-access external SSD/HDD kit
  • DC 9V to 48V wide range power input
  • Supports Panel Mount and VESA Mount (75 x 75, 100 x 100)
  • IP65 Front Panel Protection
  • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS

MTC-7010W

  • 10.1″ 1280 x 800 (16:10) WSVGA TFT LED LCD
  • 10-point projected capacitive multi-touch screen
  • 8th Generation Intel® Core™ i7/i5/i3 U-series processor (Whiskey Lake)
  • Fanless design supports -5°C to 55°C operating temperature
  • 4-port 10G USB 3.1 Gen 2
  • Easy-access external SSD/HDD kit
  • DC 9V to 48V wide range power input
  • Supports panel mount and VESA mount (75 x 75)
  • IP65 front panel protection
  • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS

MTC-8021W

  • 21.5″ 1920 x 1080 (16:9) Full HD TFT LED LCD
  • 10-point Projected Capacitive Multi-touch Screen
  • Intel Atom® x7-E3950 Processor
  • Fanless design supports -10°C to 60°C operating temperature
  • Easy-access external SSD/HDD kit
  • DC 9V to 36V wide range power input
  • Supports panel mount and VESA mount (75 x 75)
  • IP65 Front Panel Protection
  • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS

MTC-8015W

  • 15.6″ 1366 x 768 (16:9) WXGA TFT LED LCD
  • 10-point projected capacitive multi-touch screen
  • Intel Atom® x7-E3950 Processor
  • Fanless design supports -10°C to 60°C operating temperature
  • Easy-access external SSD/HDD kit
  • DC 9V to 36V wide range power input
  • Supports Panel Mount and VESA Mount (75 x 75, 100 x 100)
  • IP65 Front Panel Protection
  • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS

MTC-8015

  • 15″ 1024 x 768 (4:3) XGA TFT LED LCD
  • 10-point Projected Capacitive Multi-touch Screen
  • Intel Atom® x7-E3950 Processor
  • Fanless design supports -10°C to 60°C operating temperature
  • Easy-access external SSD/HDD kit
  • DC 9V to 36V wide range power input
  • Supports Panel Mount and VESA Mount (75 x 75, 100 x 100)
  • IP65 Front Panel Protection
  • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS

MTC-8010W

  • 10.1″ 1280 x 800 (16:10) WSVGA TFT LED LCD
  • 10-point projected capacitive multi-touch screen
  • Intel Atom® x7-E3950 Processor
  • Fanless design supports -10°C to 60°C operating temperature
  • Easy-access external SSD/HDD kit
  • Supports panel mount and VESA mount (75 x 75)
  • IP65 Front Panel Protection
  • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS

Applications & Markets

  • 19 Infrastructure

    Infrastructure

  • 7 Io T Industry 4 0

    IIoT & Industry 4.0

  • 16 Kiosk POS Digital Signage

    Kiosk, POS & Digital Signage

Technologies

  • Shutterstock 1901551972

    Panel PCs & HMI

  • Touchscreen

    Touchscreen technologies

Vecow

Vecow is committed to designing, developing and producing industrial-grade computer products; all of them are leading in performance, trusted in reliability, exhibit advanced technology, and innovative concepts.

Read more
Vecow logo

Documents

  • MTC-7021W
  • MTC-7015W
  • MTC-7015
  • MTC-7010W
  • MTC-8021W
  • MTC-8015W
  • MTC-8015
  • MTC-8010W
