GoBridge ASSP products for USB peripheral bridges

11/02/2022

GWU2U is an ASSP bridge chip in the Gowin Gobridge family that converts USB to/and from UART peripheal interfaces . It is a highly integrated, low-power, and single-chip solution for communicating with a UART peripheral interface over USB.

GWU2X is the first interface bridge ASSP chip in the Gowin Gobridge family. It is a highly integrated, low-power, and single-chip solution for communicating with peripheral interfaces over USB. It is designed to bridge SPI, I2C, JTAG, and GPIO.

Main Features

GWU2U

Supports full-speed USB device interface, compatible with the USB v1.1 specification.
Built-in USB protocol processing, without device firmware programming.
Supports USB to UART function;
Supports full-duplex asynchronous communication with built-in independent transceiver buffers.
Supports data baud rate: 64bps~4Mbps.
Supports 5/6/7/8 bit width.

GWU2X

Supports full-speed USB device interface, compatible with the USB v1.1 specification.
Built-in USB protocol processing, without device firmware programming.
Supports USB to JTAG/ SPI/ I2C.
Independent I/O power supply, supports multiple level standards.
16 general-purpose input and output pins.
Supports I2C, SPI and JTAG host interfaces with adjustable clock and independent data receive buffer.
