The GateMate FPGA family sets a new standard for small to mid-sized FPGA's and carries the "Made in Germany"-label.
Very low power and speed applications are feasible. Logic capacity, power consumption, package size and PCB compatibility are best in class. GateMateTM FPGAs combine these features with lowest cost in industry making the devices well suited from University projects to high volume applications.
| Device | Rel. size | CPE's | 8-Inp-LUT trees | FF/Latches | Block RAM 20Kb | Block RAM 40Kb | PLLs | SERDES | I/Os single-ended | I/Os Differential | Package balls | Package size (mm) |
| CCGM1A1 | 1 | 20.480 | 20.480 | 40.960 | 64 | 32 | 4 | 1 | 162 | 81 | 324BGA | 15x15 |
| CCGM1A2 | 2 | 40.960 | 40.960 | 81.920 | 128 | 64 | 8 | 2 | 162 | 81 | 324BGA | 15x15 |
| CCGM1A4 | 4 | 81.920 | 81.920 | 163.840 | 256 | 128 | 16 | 4 | 154 | 77 | 324BGA | 15x15 |
| CCGM1A9 | 9 | 184.320 | 184.320 | 368.640 | 576 | 288 | 36 | 9 | tbd | tbd | tbd | tbd |
| CCGM1A16 | 16 | 327.680 | 327.680 | 655.360 | 1.024 | 512 | 64 | 16 | tbd | tbd | tbd | tbd |
| CCGM1A25 | 25 | 512.000 | 512.000 | 1.024.000 | 1.600 | 800 | 100 | 25 | tbd | tbd | tbd | tbd |
Cologne Chip follows the latest developments in broadband access technologies, providing its ISDN transceivers to all kinds of Residential Gateways for the Central European market.
