8-Cell Analog Front End for Li-Battery Protection

29/03/2024

The new HT7Q2552 provides an I²C interface to control system configuration and MCU communication as well as supporting short-current discharge protection, high-voltage wake-up and interrupt return for over-temperature chip protection. This device has been specifically designed for use in a wide range of products such as handheld electronic tools, gardening tools, handheld vacuum cleaners etc.

The HT7Q2552 integrates a battery balance circuitry, a 5V high accuracy regulator, an accurate 2.5V reference voltage output, an individual cell voltage monitor, two discharge N-type MOSFET gate drivers, a charge N-type MOSFET gate driver, a charge/discharge differential current monitor, a discharge short-current protection, two high-voltage wake-up pins and an over-temperature chip protection function. The internal battery balance circuitry provides a balanced cell current without the need for external transistors.

Main Features

  • VIN input range from 7.5V to 36V
  • Individual cell voltage monitor outputs 1/2 of battery cell voltage, when the analog output is 2.1V, it has an accuracy of ±7.5mV
  • Internal cell charging balance switches
  • Integrated voltage regulator with 5V/50mA and ±1% accuracy
  • At Ta=-40oC~85oC, 2.5V reference voltage output with a maximum variation of 15mV in temperature drift
  • Two Discharge N-type MOSFET gate drivers
  • Single Charge N-type MOSFET gate driver
Documents Tech question
Holtek HT7 Q2552

8-Cell Analog Front End for Li-Battery Protection
