40V, 0.8A, 10-Channel, Half-Bridge Motor Driver with Serial Input Control

04/02/2022

The MPQ6527-AEC1/MP6527 is a ten-channel half-bridge DMOS output driver with integrated power MOSFETs designed for driving various loads in automotive and industrial applications (e.g. DC motors).

It can achieve up to 0.8A of output current (IOUT) across a wide 5.5V to 40V input voltage (VIN) range. The half-bridges can be controlled separately via a standard serial data interface, and each half-bridge has various diagnostic functions (shorted output, open-load detection, over-temperature, over-voltage, and under-voltage). The device has a very low quiescent current (down to 1μA) in standby mode, and has a typical 1.3Ω HS-FET and LS-FET on resistance. Robust protection features are provided to guarantee safe operation. Full protection features include under-voltage lockout (UVLO) protection, over-voltage lockout (OVLO) protection, output short-circuit protection (SCP), and over-temperature protection (OTP). The MPQ6527-AEC1/MP6527 is available in a TSSOP-28EP package, and is available in AEC-Q100 Grade 1.

Main Features

  • Wide 5.5V to 40V Operating Input Voltage (VIN) Range
  • High-Side MOSFET (HS-FET) and Low-Side MOSFET (LS-FET) Drivers Connected in Half-Bridge Configurations
  • Up to 0.8A of Output Current (IOUT)
  • Typical 1.3Ω HS-FET and LS-FET RDS(ON)
  • Low Quiescent Current (IQ) in Standby Mode
  • Short-Circuit Protection (SCP)
  • Over-Temperature Protection (OTP)
  • Under-Voltage Lockout (UVLO) Protection
  • Over-Voltage Lockout (OVLO) Protection
Documents Tech question
MPS MPQ6527 AEC1 MP6527

40V, 0.8A, 10-Channel, Half-Bridge Motor Driver with Serial Input Control
