09/06/2023
The BC7262 is suitable for Bluetooth bidirectional transmission smart products in application areas such as sensing, security, remote control, lighting control, health care, etc.
The device has an operating voltage ranging from 1.9V to 3.6V, a standby current of 0.35μA and a programmable transmitting power of up to +7dBm. The RF characteristics of the BC7262 are compliant with ETSI/FCC specifications and support the BT5.2 specification with BQB certification. The device uses an internal I²C interface to communicate with a master MCU for device setup. It is supplied in a 10-pin SOP-EP small package type and meets with the industrial specification operating temperature of -40°C~85°C.
