World's First Secure Sub-GHz SoCs With 1+ Mile Wireless Range And 10+ Year Battery Life

01/10/2021

New sub-1-GHz (sub-GHz) SoCs, delivering the world's first sub-GHz wireless solutions that combine long-range RF and energy efficiency with certified Arm PSA Level 3 security to meet the global demand for high-performance, battery-powered IoT products. Expanding the company's award-winning Series 2 platform, EFR32FG23 (FG23) and EFR32ZG23 (ZG23) system-on-chip (SoC) solutions provide developers with flexible, multiprotocol sub-GHz connectivity options supporting a wide range of modulation schemes and advanced wireless technologies, including Amazon Sidewalk, mioty, Wireless M-Bus, Z-Wave and proprietary IoT networks.

The new FG23 and ZG23 wireless SoC solutions offer an optimized combination of ultra-low transmit and receive radio power (13.2 mA TX at 10 dBm, 4.2 mA RX at 920 MHz) and best-in-class RF (+20 dBm output power and -125.3 dBm RX at 868 MHz, 2.4 kbps GFSK), making it possible for IoT end nodes to achieve 1+ mile wireless range while operating on a coin cell battery for 10+ years. These SoCs also leverage Secure Vault™, certified PSA Level 3, enabling developers to safeguard IoT products against software and hardware attacks which can compromise intellectual property, ecosystems and brand trust. FG23 and ZG23 SoCs enable developers to create IoT products that enhance the efficiency and performance of a wide range of applications including smart infrastructure, metering, environmental monitoring, connected lighting, industrial controls, electronic shelf labels (ESL), building and home automation.

Main Features

EFR32FG23 Sub-GHz Wireless SoC:

  • 32-bit ARM® Cortex®-M33 core with 78 MHz maximum operating frequency
  • Up to 512 kB of flash and 64 kB of RAM
  • Energy-efficient radio core with low active and sleep currents
  • Integrated PA with up to 20 dBm (subGHz) TX power
  • Robust peripheral set and up to 31 GPIO


Z-Wave 800 Modem SoC (EFR32ZG23):

  • Low Power Z-Wave Wireless SoC
  • 32-bit ARM® Cortex®-M33 core with 78 MHz maximum operating frequency
  • Up to 512 kB of flash and 64 kB of RAM
  • Integrated sub-GHz PA with up to 20 dBm TX power
  • Integrated LNA with RX Sensitivity as low as -109.8 dBm.
  • Secure Element with Secure Vault
  • Robust peripheral set and up to 31 GPIO
