Workstation-grade expandable fanless embedded system

27/11/2020

Armed with workstation-grade 10 cores 10th generation Intel® Xeon®/Core™ i9/i7/i5/i3 processor (Comet Lake) and Intel® W480E chipset, Fanless, -40°C to 75°C operating temperature, 6 GigE LAN with 4 X-coded M12 PoE+, 6 USB 3.2 connections supporting up to 10Gbps data rate, SIM sockets supporting 5G/WiFi/4G/3G/LTE/GPRS/UMTS mobile availability, M.2, Mini PCIe and PCI/PCIe expansions for versatile configurations, smart manageability, 9V to 50V power input with 80V surge protection, software ignition power control, smart circuit protection and trusted reliability, Vecow ECX-2200/2100 Series Workstation-grade Expandable Fanless Embedded System is your ideal choice for Machine Vision, Rolling Stock, Smart Retail, Vehicle Computing, AMR/AGV, and any AIoT-oriented real-time embedded applications.

Documents Tech question
6683 1

Workstation-grade expandable fanless embedded system

  • Features
  • Applications
  • Technologies
  • Manufacturer
  • Documents

Features:

  • Workstation-grade Platform : 10-core 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3 Processor (CML-S) running with Intel® W480E chipset supports max 95W TDP CPU
  • 2 DDR4 2933MHz Memory support up to 64GB, optional with ECC
  • 9V to 50V wide range DC Power Input with 80V Surge Protection
  • Fanless, -40°C to 75°C Operating Temperature
  • 6 Independent GigE LAN with 4 X-coded M12 IEEE 802.3at PoE+
  • PCIe x16 expansion supports up to 250W Power Budget
  • Expansion : 1 PCIe, 1 M.2 Key B, 1 M.2 Key E, 2 Mini PCIe, optional SUMIT A, B
  • Storage : 2 2.5″ SSD Tray, 1 Micro SD Card, 1 M.2 Key M, 2 SATA III
  • Display : VGA, DVI-D & 2 DisplayPort interfaces, up to 4K resolution
  • 6-port USB 3.2 support up to 10Gbps data transfer
  • 32 Isolated DIO, 4 COM RS-232/422/485
  • 3 External Nano SIM Sockets for 5G/WiFi 6/4G/3G/LTE/GPRS/UMTS
  • Supports Configurable Software Ignition Power Control and TPM 2.0
  • Optimized user-friendly design for easier system maintenance
  • Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications

Applications & Markets

  • 5 Industrial Automation

    Factory & Industrial Automation, Robotics

  • 7 Io T Industry 4 0

    IIoT & Industry 4.0

Technologies

  • Shutterstock 740406568

    Industrial PC & systems

  • Shutterstock 570647902

    Machine vision

Vecow

Vecow is committed to designing, developing and producing industrial-grade computer products; all of them are leading in performance, trusted in reliability, exhibit advanced technology, and innovative concepts.

Read more
Vecow logo

Documents

  • ECX-2200/2100
