Wide Temp. Fanless Designed Box PC FPC-8107 with 3 Expansion Slots

20/08/2021

The advanced new FPC-8107 includes plenty of onboard I/O, unparalleled expansion and configuration flexibility, and scalable performance to address numerous applications and project requirements, making it suitable for use in a wide range of industrial environments with particular emphasis on Industry 4.0 automation applications.

FPC-8107 offers three standard configurations which includes 1x PCIe x16 + 2x PCI, 2x PCIe x16 + 1x PCIe x4, or 3 x PCI configurations.

Its fanless design makes dust accumulation avoidable and industrial-grade FPC-8107 comes with a wide operating temperature range from -20ºC to 70ºC and storage temperature range from -40 ºC to 85 ºC.

It provides six COM ports (RS-232), three GbE LANs, six USB 3.2 Gen1 ports, and two USB 2.0 ports, and one DB25 connector for DI/O. FPC-8107 also comes with HDMI, DVI-D and VGA outputs to connect multiple monitors and it can support 2 independent displays.

Main Features

  • Fanless design
  • Wide range DC power input (9~36V)
  • Two independent displays support (HDMI x1 + VGA x 1 and DVI-D x 1)
  • Power on/off delay control/ configurable ignition power control
  • TPM2.0 support
  • 1x mPCIe for optional Wi-Fi/ 3G/ 4G/ GPS or I/O expansion supported
  • Up to 3x expansion slot support
  • 1x M.2 E Key (2230) for Wi-Fi/ BT
  • Intel® Wi-Fi 6 AX200 support
Documents Tech question
Header 700x290

Wide Temp. Fanless Designed Box PC FPC-8107 with 3 Expansion Slots

  • Features
  • Applications
  • Technologies
  • Manufacturer
  • Documents
Schermafbeelding 2021 08 16 135646

Applications & Markets

  • 5 Industrial Automation

    Factory & Industrial Automation, Robotics

Technologies

  • Shutterstock 740406568

    Industrial PC & systems

Arbor

Arbor is a global provider of dedicated industrial IoT computing and mobility solutions.

Read more
Arbor Logo

Documents

  • FPC 8107 Datasheet 20210810
