Valens Expands Portfolio of Stello VS3000 Chipset Family

25/06/2021

The new product offering includes the VS3100, VS300R, and VS310R, which join the previously announced, fully featured VS3000. The Valens Stello VS3000 chipset family include highly integrated ICs for the convergence and extension of A/V signals over a single standard Category cable. The Stello chipsets enable the extension of uncompressed HDMI 2.0 (18Gbps – 4K@60 4:4:4), high fidelity audio, 1Gbps ethernet, USB2.0, controls, and power, over a CAT cable for up to 100 meters (328 feet), with zero latency. The Stello chipsets implement HDBaseT 3.0 spec and are backwards compatible with HDBaseT spec 2.0 and spec 1.0 products, providing interoperability with existing installations.

Main Features

Convergence of multiple native interfaces over a single Cat 6a cable (U/FTP), including:

Video: Uncompressed HDMI 2.0 4K@60Hz 4:4:4, 8-bit resolution
Audio: I2S-4 and S/PDIF
Ethernet: 1Gbps
USB: High speed USB 2.0
Controls: I2C, UART and CIR
Power: PoH (power over HDBaseT), based on IEEE 802.3a/bt
Highly integrated chipset
Concurrent ‘HDMI in’ and ‘HDMI out’ native ports
Audio Extract and Insert functionality on ‘HDMI in’, ‘HDMI out,’ and the HDBaseT port
HDCP2.3 repeater
Internal HDBaseT packet switching core
HDBaseT port duality, enabling a single hardware design to support both Tx and Rx
Backwards compatible with VS100 and Colligo VS2000 Valens product families

Documents Tech question

Applications & Markets

Technologies

Audio, video, multimedia

Valens

Valens is the inventor and world leader in HDBaseT technology, the only solution for the transmission of high-throughput video and data streams in the AV, automotive, industrial and consumer marketplaces.
