USB PD Source Controller with 7 Configurable PDOs and Load-Shedding

25/10/2024

The MP5038 is a USB power delivery (PD) controller compatible with USB Type-C 2.1 and USB PD 3.0 specifications. It targets downstream-facing port (DFP) provider applications, such as charging-only USB PD ports and USB hubs.

The MP5038 is backwards compatible, supporting downstream-charging port (DCP) schemes for Quick Charge (QC) 3.0, BC1.2 battery charging specifications, Apple Divider mode, Huawei fast charge protocol (FCP), and 1.2V/1.2V mode without outside user interaction. It also supports BC1.2 charging downstream port (CDP) handshaking. The I2C interface and GPIO pins provide good communication with an external power converter.

Main Features

  • Supports 3.3V to 21V Bus Voltage (VBUS) Range
  • 4.6V to 5.5V Supply Voltage (VCC) Range
  • Support Up to 7 Configurable Power Delivery Objects (PDOs)
  • Integrated Physical Layer for Battery Management Controller (BMC)
  • Integrated Protocol Layer
  • Integrated Policy Engine
  • Low Standby Quiescent Current (IQ): 100μA
  • Supports One USB Type-C Downstream-Facing Port (DFP) with USB PD 3.0 and Programmable Power Supply (PPS)
  • Supports Downstream-Charging Port (DCP) Schemes for BC1.2
  • Apple Divider 3 Mode and 1.2V/1.2V Mode
Documents Tech question
MPS MP5038

USB PD Source Controller with 7 Configurable PDOs and Load-Shedding

  • Applications
  • Technologies
  • Manufacturer
  • Documents

Applications & Markets

  • 25 Mobile Wearables

    Mobile & Wearables

  • 27 White Goods Home Appliances

    White Goods & Home Appliances

Technologies

  • Shutterstock 1632356350

    Microcontroller, microprocessors & memory ICs

Monolithic Power Systems

Monolithic Power Systems provides small, highly energy efficient, easy-to-use power solutions for systems found in industrial applications, telecom infrastructures, cloud computing, automotive, and consumer applications.

Read more
Monolithic Power Systems Logo

Documents

  • MPS MP5038 Datasheet
