Main Features
CPU Features:
- Operating Voltage
- fSYS =8MHz: 1.8V~5.5V
- fSYS =12MHz: 2.7V~5.5V
- fSYS =16MHz: 3.3V~5.5V
- Up to 0.25μs instruction cycle with 16MHz system clock at VDD =5V
- Power down and wake-up functions to reduce power consumption
- Oscillator types
- External High Speed Crystal – HXT
- Internal High Speed 8/12/16MHz RC – HIRC
- External Low Speed 32.768kHz Crystal – LXT
- Internal Low Speed 32kHz RC – LIRC
- Multi-mode operation: FAST, SLOW, IDLE and SLEEP
Peripheral Features:
- Flash Program Memory: 4K×16
- RAM Data Memory: 256×8
- True EEPROM Memory: 128×8
- Watchdog Timer function
- In Application Programming – IAP
