Sub-1GHz OOK/FSK RF Transmitter Touch MCU

21/01/2022

The new series BC66F2235 / BC66F2245 / BC66F2255 of devices are SoC chips which integrate an RF transmitter, touch key functions in addition to an A/D Flash MCU core. This set of powerful functions allows the devices to meet with the requirements of RF and Touch applications, such as wireless doorbells, wall touch switches, integrated ceiling remote controls, smart clothes hanger remote controls and other related products.

This series of devices include a Flash Program Memory capacity of 2K/4K/8K×16, a Data Memory capacity of 352×8, two Compact type 10-bit Timer Modules and one Periodic type 10-bit Timer Module, a 1-/4-/4-channel 12-bit A/D converter, an IAP function and an SPI/I²C/UART communication interface module. These devices also provide 8/14/16 touch keys, with an ultra-low power consumption having a standby current less than 4μA at 3V/25℃ for a single touch key. In addition, the devices have a programmable RF transmission power of up to +13dBm. The integrated RF transmitter meets with ETSI/FCC safety specification requirements.

This series of devices are supplied in 16-pin NSOP-EP, 24-pin SSOP-EP and 32-pin QFN package types and meet with the industrial specification requirements of -40°C~85°C operating temperature. The professional Holtek RF and Touch service teams also stand ready to provide technical support which offers customers a means of rapid application development.

Main Features

CPU Features:

  • Operating voltage
  • fSYS=8MHz: 2.0V~3.6V
  • fSYS=16MHz: 2.0V~3.6V
  • Up to 0.25μs instruction cycle with 16MHz system clock at VDD=5V
  • Power saving and wake-up functions to reduce power consumption


Peripheral Features:

  • Flash Program Memory: 2K×16~8K×16
  • RAM Data Memory: 256×8
  • Touch Key Data Memory: 96×8
  • Up to 16 touch key functions – fully integrated without requiring external components


RF Transmitter Features

  • Complete ultra high frequency OOK/FSK transmitter with low transmission phase noise
  • Supports 315/433/868/915MHz frequency bands
  • Programmable channel setting with < 2kHz resolution
  • OOK symbol rates 0.5Ksps~25Ksps, FSK data rates 0.5Kbps~100Kbps
Documents Tech question
Holtek BC66 F2235 2245 2255

Sub-1GHz OOK/FSK RF Transmitter Touch MCU

  • Applications
  • Manufacturer
  • Documents

Applications & Markets

  • 27 White Goods Home Appliances

    White Goods & Home Appliances

Holtek

Holtek Semiconductor is a leading professional IC design house in Taiwan having its major business activities focused in the area of microcontroller and peripheral component design.

Read more
Holtek semiconductor logo web

Documents

  • Holtek BC66 F2235 45 55v100 Datasheet
