Main Features
- Supports 100Base-X, 1000Base-X SFP ports
- Supports Redundancy protocols: DT-Ring (recovery time<50ms), DRP/DHP (recovery time <20ms), STP/RSTP/MSTP
- Supports Network Security: HTTPS/SSL, SSH, TACACS+, IEEE802.1X, Radius, User Classification, MAC address binding with switch ports
- Supports CLI, Telnet, WEB management methods, Kyvision centralized management based on SNMPv1/v2c/v3
- Supports Automatic Configuration Backup and Restore
- Supports Hardware-based IEEE1588 PTPv2 (BC, P2P TC, E2E TC clock modes, synchronization precision ±100 ns)
- Supports PROFINET (-PN Model), EtherNet/IP and Modbus/TCP protocols
- Supports DDM(SFP port)
- Supports IP40 protection
- Complies with IEC61850-3 and IEEE1613
- CE, FCC, CB, EN50121-4, UL61010, Class I Div 2, IECEx, ATEX, WEEE certificates
