New rugged panel PCs

19/08/2022

New-generation rugged panel PCs with touchscreen – the ARC-1535 with Intel® Atom® x6211E/x6413E/x6425E processor and the ARC-1538 with 11th Gen Intel® CoreTM i7/i5/i3 processor. The ruggedized ARC series are specifically designed to be waterproof, dustproof, shockproof and scratchproof. Able to survive high humidity, temperature and vibration, they are ideally suitable for operation in harsh environment, ensuring that machines continue working normally without disruption.

The ARC series are suitable for using in diverse application scenarios, including industrial automation (e.g. HMI, heavy-industry manufacturing, non-stop production process and industrial automation), rehabilitation equipment (e.g. decompression machine, rehabilitation machine and training machine), and automated kiosks (e.g. automated vending machine, ATM, interactive kiosk and payment machine). The emphasis of Avalue’s ARC series design includes IP-65 rated water and dust resistance, wide operating temperature range, sunlight readable, support 5G and Wi-Fi 6 wireless transmission, and coating technology for PCAP touchscreen, making it the ideal solution for all applications whether indoor or outdoor.

Main Features

ARC-1535 main features:

Onboard Intel® Atom™ Elkhart Lake x6211E/x6413E/x6425E Processor
Full Flat Front Panel with Projected Capacitive Touch Supports Multi Touch
One 260-pin SODIMM sockets supports up to 32GB DDR4 3200 SDRAM
4 x USB3.2, 2 x COM
Dual Intel Gigabit LAN
2 x M.2 Slots (Key-B 2242/3042/3052, Key-E 2230)
Support Wi-Fi / BT / 4G / 5G (by option)
Wide Voltage +12V ~ +24V Input, ErP Power
Available Expansion for Audio, USB, COM, HDMI, MPCIe, GPIO, CAN Bus
IP65 Compliant Front Panel, IP41 Rear Box
With Panel Mount kits included
TPM 2.0 Function (Optional)
Fanless Operation Wide temp. from -20°C ~ 55°C (-4°F ~ 131°F)

ARC-1538 main features:

Onboard 11th Gen. Intel®Core™ i7/i5/i3 BGA Processor
Full Flat Front Panel with Projected Capacitive Touch Supports Multi Touch
One 260-pin SODIMM sockets supports up to 32GB DDR4 3200 SDRAM
4 x USB3.2, 2 x COM
Dual Intel Gigabit LAN2 x M.2 Slots (Key-B 2242/3042/3052, Key-E 2230)
Support Wi-Fi / BT / 4G / 5G / NVMe (by option)
Wide Voltage +12V ~ +24V Input, ErP Power
Available Expansion for Audio, USB, COM, HDMI, MPCIe, GPIO, CAN Bus
IP65 Compliant Front Panel, IP41 Rear Box
With Panel Mount kits included
TPM 2.0 Function (Optional)
Fanless Operation from -10°C ~ 50°C (14°F ~ 122°F)
