New RP395 EMI Filter for High Power

20/12/2024

The RP395 3-phase delta 1000 VAC EMI power line filter is designed to support the new generation of power conversion systems utilizing high-voltage AC. The filter series supports rated currents ranging from 150A to 2500A, offering OEMs adaptability for different power levels and delivering superior insertion loss performance against electromagnetic interference. To make things more exciting, the 3500A design is near completion and will be released soon.

These filters are designed to operate at 1000 VAC nominal voltage, with a +10% tolerance (max). The 1000VAC limit ensures that the system still falls within the scope of the LV (low voltage) safety directive and doesn’t need to comply with more onerous medium voltage safety requirements.

RP395 EMI filters are ideally suited for:

  • Hydrogen Generation/Electrolyzer
  • Energy Storage Systems (ESS/BSS)
  • High-current rectifiers
  • High power inverters
  • Megawatt chargers

Main Features

  • Rated currents include 150A, 180A, 250A, 320A, 400A, 600A, 800A, 1000A, 1600A and 2500A
  • Multi-Stage Line Filter
  • Available with W (wires), S (studs), C (connectors) and B (Bus Bars) option
  • Agency Approved to UL1283 / 60929, CSA C22.2, EN60939 (Up to 2500A Testing successfully completed. Certificate in process.)
  • Y-cap value can be adjusted to fit specification
