Main Features
CPU Features
- Operating Voltage
- fSYS=4MHz: 2.2V~5.5V
- fSYS=8MHz: 2.2V~5.5V
- fSYS=12MHz: 2.7V~5.5V
- fSYS=16MHz: 3.3V~5.5V - Up to 0.25μs instruction cycle with 16MHz system clock at VDD=5V
- Power down and wake-up functions to reduce power consumption
- Oscillator Types
- External High Speed Crystal – HXT
- Internal High Speed 4/8/12MHz RC – HIRC
- External Low Speed 32.768kHz Crystal – LXT
- Internal Low Speed 32kHz RC – LIRC - Fully integrated internal oscillators require no external components
Peripheral Features
- Flash Program Memory: 32K×16
- Data Memory: 2048×8
- True EEPROM Memory: 2048×8
- In Application Programming function – IAP
- Internal On-Chip Debug Support function – OCDS
