New EtherCAT Modules Completing Solution for Industrial Automation

23/04/2021

New 6-CH EU Series, and ECAT-4XMO and ECAT-TRG4 modules integrate hardware and software to modernize IIoT-based smart factories

ADLINK provides the full spectrum of the EtherCAT solution, including master modules and slave modules, bundled together at a cost-effective price point
In test applications, the EtherCAT system delivered total cost of ownership (TCO) savings of up to 10% and up to 30% increases in productivity
Speeds development and deployment of machine automation and industrial automation including glass inspection, assembly machines, lens tests, automated optical inspection, dispensing, and more

ECAT-4XMO motion control and trigger module, and the ECAT-TRG4 trigger module are a dynamic extension to ADLINK’ s EtherCAT System and are designed to perfectly complement the EU Series, enabling higher performance in automatic assembly, test, and inspection equipment across a multitude of applications including cell phone glass inspection, battery cell assembly, camera lens assembly and test and glue dispensing machinery, as well as inspection equipment.

ADLINK launches new Ether CAT modules 21041315380677988

Features:

4 table trigger—10 Mhz max w/ FIFO 255 points
4 linear trigger—10 Mhz max.
4 channel latch response—3 MHz max. w/ 255 points
Hardware emergency stop interface
Supports gantry function up to 32 sets with master
Power-off memory for axis parameter
Supports encoder re-driver function
Supports advanced point table
