New 10.1” PCAP display series

20/11/2020

This FLC-101HML2000SA1#00 is a superior TFT LCD from point of view of specification and endurance but with competitive price.
The display unit is available with 3 different touch option assembled by DSA and also a ready to go AD board in two versions: one with HDMI only interface and 12V power input, the other with VGA-DVI-DP interface with extended power input from 14V to 32V.

3 optional RockTouch Projected Capacitive touch solution assembled with TFT are:

  • 1.1 mm glass transparent with USB/I2C combo interface (P/N FLD-101HML20PCSA5#00)
  • 1.8 mm glass black bezel with USB interface and external DSA (P/N FLD-101HML20PUFA2#00)
  • 3 mm glass black bezel with USB/I2C combo interface (P/N FLD-101HML20PCSA4#00)
Documents Tech question
Rocktouch

New 10.1” PCAP display series

  • Features
  • Applications
  • Technologies
  • Manufacturer
  • Documents
  • Technology and size: 10.1”W TFT LCM
  • Resolution: 1280×800
  • Glass technology: AAS (IPS like)
  • Contrast 800:1
  • Brightness 500 nits
  • Backlight lifetime: 50.000 hours
https://eur01.safelinks.protection.outlook.com/?url=https%3A%2F%2Frocktouch.us15.list-manage.com%2Ftrack%2Fclick%3Fu%3Df1dbef3d09ebb916a3f4f52d1%26id%3D77f9a42a68%26e%3Dc4f1cdb365&data=04%7C01%7Cluc.spiessens%40alcom.be%7C670efe10cc284b14d12a08d87698c175%7Cca004b9b272d4be6b73dcc2398af910d%7C0%7C0%7C637389745750458487%7CUnknown%7CTWFpbGZsb3d8eyJWIjoiMC4wLjAwMDAiLCJQIjoiV2luMzIiLCJBTiI6Ik1haWwiLCJXVCI6Mn0%3D%7C1000&sdata=W3OhRIFt7gPO%2B6FIRfaJ013G%2BmAg6Le2YXrKt65AsyI%3D&reserved=0

Applications & Markets

  • 17 Home Building Automation

    Home & Building Automation

  • 5 Industrial Automation

    Factory & Industrial Automation, Robotics

Technologies

  • Touchscreen

    Touchscreen technologies

  • 65 rocktouch

    TFT-LCD displays

Rocktouch

Rocktouch is a technology driven company for the Projected Capacitive Touch Screen Solution.

Read more
Rocktouch Logo

Documents

  • Rocktouch FLC 101 HML20 Series Rev02
