Linear Hall-Effect Current Sensor

23/09/2022

The MCS1823 is a linear Hall-effect current sensor IC for AC or DC current sensing. The Hall array is differential to cancel out any stray magnetic field. A low-resistance (0.6mΩ) primary conductor allows a large current to flow within close proximity to the integrated circuit containing high-accuracy Hall sensors.

Main Features

  • 3V or 5V Single Supply (Optional)
  • Immune to External Magnetic Fields by Differential Sensing
  • 6mΩ Internal Conductor Resistance
  • ±2.5% Total Accuracy
  • 5A to 50A Range (See Ordering Information)
  • 120kHz Bandwidth
  • Over-Current Detection (OCD) with 1μs Response Time
  • Output Proportional to AC or DC Currents
  • Ratiometric or Absolute Output from Supply Voltage (Optional)
  • Factory-Trimmed for Accuracy
  • No Magnetic Hysteresis
  • Custom OCD Level from 50% to 240% of IPMAX
  • Available in a QFN-12 (3mmx3mm) Package
