Main Features
- 128M-bit Serial Flash
- Standard, Dual, Quad SPI, QPI
- High Speed Clock Frequency
- Software/Hardware Write Protection
- Endurance and Data Retention
- Allows XiP (eXecute In Place) Operation
- Fast Program/Erase Speed
This browser is not fully supported.
This website uses cookies to provide you with a better visitor experience. Select here which type of cookies you allow.
Alcom electronics appreciates the potential business relationship between our parties. Thank you! We want to make sure we address only the mailings that are valuable to you.
With its thickness of only 0.4mm, the GD25LE128EXH offers designers unparalleled flexibility in designing compact applications, making it the ideal code storage unit for IoT, wearables, healthcare, and networking products that demand high functionality and low power consumption.
The GD25LE128EXH features outstanding performance, with a maximum frequency of 133MHz and a data throughput of up to 532Mbit/s, significantly enhancing system access speed and instant-on capability. Compared to other industry products, the GD25LE128EXH operates at a lower read current of only 6mA when running at 4-channel 133MHz frequency, reducing the power consumption by 45% and effectively extending battery life. The GD25LE128EXH achieves an ultra-small size for 128Mb products by using the new FO-USON8 package, which reduces area by 70% and thickness by 50%, compared to the conventional 6x5x0.8mm WSON8 package typically used for such products. As a result, GD25LE128EXH takes up 85% less space and reduces material cost.
Giga Device is a Semiconductor Technology leader focused on Flash memory, Microcontroller, Sensor and Analog products. Giga Device can provide a wide range of solutions and services in the fields of industrial, automotive, computing, consumer electronics, IoT, mobile, networking and communications.
