High-Performance Expandable 2U Workstation

20/01/2023

New 19-inch high-performance 2U rackmount server HPS-621U2A. Ideal for limited space and expandable to accommodate increase in workload, HPS-621U2A server supports 1st-Gen and 2nd-Gen Intel® Xeon® scalable processors, Intel C621 chipset, seven low-profile PCIe/PCI slots, and six DDR4 RDIMM and LRDIMM slots. Designed for flexible storage, HPS-621U2A provides four 5.25-inch storage bays which are convertible to 2.5-inch or 3.5-inch drive bays depending on requirement. Furthermore, it supports M.2 M-key PCIe 3.0x4 NVMe SSD, and is equipped with a wide variety of I/O interfaces (1 x RS232, 1 x VGA, 4 x RJ-45 network connectors), 500W 80 plus gold PSU with at least 87% efficiency rating, and four fans which save energy consumption through IPMI (Intelligent Platform Management Interface) 2.0 while achieving excellent heat dissipation.

Main Features

  • 19" 2U Chassis
  • 483mm(W) x 88mm(H) x 650mm(D)
  • 1 x 1U 80plus Gold 500W PSU
  • 4 x External 5.25" storage bay & 2 x Internal 3.5’’ storage bay
  • Intel FCLGA3647 Socket supports 1st and 2nd Gen. Intel
  • Xeon Scalable processors (Max. TDP at 150W)
  • Intel C621 chipset
  • 6 x DDR4 2933/ 2666/ 2400/ 2133 MHz RDIMM/LRDIMM up to 768GB
  • IPMI 2.0 with AST 2500 BMC controller onboard
  • 4 x Intel I210AT Giga-bit Ethernet
Documents Tech question
Avalue HPS 621 U2 A

High-Performance Expandable 2U Workstation
