Main Features
Express-ID7
- AVX-512 VNNI for AI inference, data analysis
- Up to 128GB DDR4 SO-DIMM, 2933MT/s, ECC
- 4x 10G Ethernet and NC-SI support
- 16 PCIe Gen4 lanes and 16 PCIe Gen3 lanes
- 10+ year product availibility
- Extreme Rugged operating temperature: -40°C to 85°C (build option, selected SKUs)
Express-ADP
- Performance hybrid architecture (P-core, E-core)
- Up to 14 cores, 20 threads at 15W/28W/45W TDP
- Up to 64GB DDR5 SO-DIMM at max. 4800MT/s, non-ECC
- AI inference (AVX-512 VNNI, Iris Xe GPU 96EUs
- 4 displays via DDI/LVDS (opt. eDP, VGA) and USB4/Thunderbolt 4 (TBC)
- 1 PCIe x8 Gen4, 2 PCIe x4 Gen4, 2.5GbE (TSN opt.)
- Extreme Rugged operating temperature (optional, selected SKUs)
