All-in-One Kit for Rapid Prototyping and Development

29/04/2024

All-in-One kit: GD-xD-W515-Eval Board. This evaluation platform leverages various GigaDevice products, enabling customers to evaluate multiple hardware and software combinations all within one comprehensive kit.

The GD-xD-W515-EVAL Board is the first evaluation kit in the xD series, it comprises a mainboard, a fingerprint board, and an LCD board within a compact footprint. It can be powered by either a battery or the Mini-USB interface of the GD-Link programmer. Through the integration of diverse GigaDevice’s high performance MCU (GD32W515PIQ6) , SPI NOR flash (GD25Q128E), capacitive fingerprint Sensor (GSL6157), battery management IC (GD30BC2416), and high-performance power IC (GD30LD1002), this EVAL board delivers tailored solutions to customers across a spectrum of applications, such as smart home HMI, smart door lock, and portable device control.

Main Features

  • Privacy and Security: Supports secure fingerprint recognition and data management with encryption & authentication algorithm provided by GigaDevice's fingerprint sensor and MCU.
  • Fast and Secure Data Access: Includes small package NOR Flash for accessing data via the QSPI interface at a clock frequency of 45MHz. Data can be encrypted/decrypted using the MCU's Cryptographic Acceleration Unit (CAU).
  • High Efficiency Battery Charging: Supports battery charging currents of up to 1.5A.
  • System Protection: Provides USB power-on and wake-up voltage monitoring as well as battery voltage and power monitoring.
  • Accurate Battery Power Estimation: Accurately calculates battery power using current and voltage detection, optimized by the battery power calculation algorithm.
  • Touch Operation: Includes a capacitive touch key controlled by the MCU’s Touch Sensing Interface (TSI) for easy and quick operation.
Documents Tech question
Giga Device GD x D W515

All-in-One Kit for Rapid Prototyping and Development

  • Features
  • Applications
  • Technologies
  • Manufacturer
  • Documents

Applications & Markets

  • 17 Home Building Automation

    Home & Building Automation

Technologies

  • Shutterstock 1632356350

    Microcontroller, microprocessors & memory ICs

Giga Device

Giga Device is a Semiconductor Technology leader focused on Flash memory, Microcontroller, Sensor and Analog products. Giga Device can provide a wide range of solutions and services in the fields of industrial, automotive, computing, consumer electronics, IoT, mobile, networking and communications.

Read more
Giga Device Logo

Documents

  • Giga Device All in One GD x D W515 EVAL Board
