5V Wide Voltage Arm® Cortex®-M0+ 32-bit MCUs

09/12/2022

The HT32F50020/HT32F50030 devices are high performance, low power consumption 32-bit microcontrollers based around an Arm® Cortex®-M0+ processor core. The Cortex®-M0+ is a next-generation processor core which is tightly coupled with Nested Vectored Interrupt Controller (NVIC), SysTick timer and including advanced debug support.

The devices operate at a frequency of up to 16 MHz with a Flash accelerator to obtain maximum efficiency. It provides up to 32 KB of embedded Flash memory for code/data storage and 2 KB of embedded SRAM memory for system operation and application program usage. A variety of peripherals, such as ADC, I2C, UART, SPI, SCTM, BFTM, LEDC, RTC, WDT and SW-DP (Serial Wire Debug Port), etc., are also implemented in the devices. Several power saving modes provide the flexibility for maximum optimization between wakeup latency and power consumption, an especially important consideration in low power applications.

Main Features

Core

  • 32-bit Arm® Cortex®-M0+ processor core
  • Up to 16 MHz operating frequency
  • Single-cycle multiplication
  • Integrated Nested Vectored Interrupt Controller (NVIC)
  • 24-bit SysTick timer

On-chip Memory

  • Up to 32 KB on-chip Flash memory for instruction/data and options storage
  • 2 KB on-chip SRAM
  • Supports multiple boot modes

Flash Memory Controller – FMC

  • 32-bit word programming with In System Programming Interface (ISP) and In Application Programming (IAP)
  • Flash protection capability to prevent illegal access
Documents Tech question
Holtek HT32 F50020 30

5V Wide Voltage Arm® Cortex®-M0+ 32-bit MCUs

  • Applications
  • Technologies
  • Manufacturer
  • Documents

Applications & Markets

  • 17 Home Building Automation

    Home & Building Automation

  • 27 White Goods Home Appliances

    White Goods & Home Appliances

  • 12 Security Surveillance

    Security & Surveillance

Technologies

  • Shutterstock 1632356350

    Microcontroller, microprocessors & memory ICs

Holtek

Holtek Semiconductor is a leading professional IC design house in Taiwan having its major business activities focused in the area of microcontroller and peripheral component design.

Read more
Holtek semiconductor logo web

Documents

  • Holtek HT32 F50020 30 Datasheetv100
