5V CAN Wide Voltage 32-bit MCUs

19/04/2024

These devices include a Bosh licensed CAN bus controller which supports the CAN 2.0A/B protocol specifications and conforms to ISO11898-1:2003 standards. The CAN interface can be combined with the UART/USART LIN mode to form an in-vehicle network to meet related vehicle application requirements.

These new devices have an operating voltage range of 2.5V~5.5V, an industrial temperature range of -40℃~105℃ and an operating speed of up to 60MHz. Regarding memory storage, there is up to 128KB of Flash Program Memory and up to 16KB of SRAM Data memory. The devices also contain a 6-channel PDMA. In addition, the devices provide an independent VDDIO pin to facilitate the connection of external components whose voltage is different to the MCU VDD voltage. A variety of peripheral resources are included, such as CAN, EBI, DIV, SPI, UART, USART, I²C, MCTM, GPTM, PWM, BFTM, RTC, CRC, CMP, LED controller with an automatic scanning function etc. The devices contain a 12-channel SAR A/D Converter with a conversion speed of up to 2Msps whose reference voltage, VREF, can be configured as an internal reference voltage. The devices are supplied in 32/46-pin QFN and 48/64-pin LQFP package types, which provide up to 54 GPIO pins.

Documents Tech question
Ht32f53231

5V CAN Wide Voltage 32-bit MCUs

  • Applications
  • Technologies
  • Manufacturer
  • Documents

Applications & Markets

  • 3 Automotive

    Automotive

  • 5 Industrial Automation

    Factory & Industrial Automation, Robotics

  • 17 Home Building Automation

    Home & Building Automation

  • Shutterstock 2051297759

    In-vehicle computing

  • 8 Instrumentation

    T&M and instrumentation

Technologies

  • Shutterstock 1632356350

    Microcontroller, microprocessors & memory ICs

Holtek

Holtek Semiconductor is a leading professional IC design house in Taiwan having its major business activities focused in the area of microcontroller and peripheral component design.

Read more
Holtek semiconductor logo web

Documents

  • HT32 F53231 41 42 52 Datasheetv100
